Lincoln Industrial 81770-3 Centro-Matic 3 Grease Injector Manifold SL-1 Series

Contact Us to Order
$329.28

Does not ship to: CA

81770-3 Lincoln Industrial Centro-Matic Three Grease Injector Manifold SL-1 Series  FEATURES: For single-line, high-pressure central lubrication system For dispensing lubricants...

81770-3 Lincoln Industrial Centro-Matic Three Grease Injector Manifold SL-1 Series

FEATURES:

  • For single-line, high-pressure central lubrication system
  • For dispensing lubricants compatible with Viton packing and viscosity up to NLGI No.2
  • Output is externally adjustable
  • Indicator stem permits visual check of injector operation
  • May be combined in a circuit of injectors SL-32, SL-33, SL-V, SL-v XL and/or SL-11
  • Individual injectors can be easily removed for inspection or replacement
  • Available in stainless steel SAE 316, for application where environmental conditions are hazardous to carbon steel or in industries preferring stainless steel

TECHNICAL SPECS:

  • Product # - 81770-3
  • Max. Operating Pressure - 3500 psig (241/bar)
  • Min. Operating Pressure - 1850 psig (127/bar)
  • Standard Operating Pressure - 2500 psig (172/bar)
  • Manifold Inlet - 3/8" NPTF Female
  • Injector Outlet - 1/8" NPTF Female
  • Number of Outlets - 3
Notes :
  • Injectors have Viton packings.  Check compatibility with synthetic lubricants.
  • Injector rated for 350°F (176°C) max. ambient temperature, depending on lubricant used.
  • Injectors include fitting for filling feed lines via alternate outlet port.
  • Output with adjustment screw hand-tighted is .009 cu. in. Maximum output is achieved with eight turns at .009 cu. in./turn.



Comparable to Graco Injector 114903
